SolaMesh® Diamond Pad Eye

Stainless Steel Type 316 90 x 55mm (3 1/2" x 2 9/16")
Item # 207046

Sign in for
wholesale pricing

Become A Customer

Description

This industrial SolaMesh diamond pad eye provides maximum hold for commercial shade systems. Simply affix it to the support structure before installing the outdoor fabric. Made from durable stainless steel 316, the premium mounting plate is an essential component to any successful tension canopy. Applications include shade structures, like tension membrane or hip and ridge shade sails. Use with SolaMesh shade sail fabric or an equivalent HDPE knitted shade cloth.

The heavy-duty product is 90 x 50mm and backed by a 5-year warranty. Find corresponding supplies and tools, like shade sail mounting hardware, in our hardware section.

Product Note: The finished structure should be properly designed by a professional engineer and installed by a qualified contractor in accordance with local building codes. It is the responsibility of the fabricator within these parameters to determine the proper hardware for a particular installation.
Trademark: SolaMesh® is a registered trademark of Glen Raven, Inc.

Documentation

pdf
pdf
pdf
pdf

Specifications

Finish:
Stainless Steel
Product Category:
Wall Plates
Put Up:
1/each
Warranty:
5-Year
Width:
55 mm (2.17 in.)
Finish:
Stainless Steel
Length:
90 mm (3.54 in.)
Material:
Stainless Steel Type 316
Maximum Working Load:
766 kg (1,686 lbs.)
Size:
90 mm x 55 mm (3.54 in. x 2.17 in.)
